API Spec 6AV1

Click here to purchase
This specification establishes design validation requirements for API Specification 6A surface safety valves/underwater safety valves (SSV/USV) and associated valve bore sealing mechanism(s) for Class II and Class III. These classes are intended for use if substances such as sand can be expected to cause an SSV/USV valve failure.

Class III adds requirements for the validation of the valve bonnet assembly inclusive of stem seals and may be selected by the user/purchaser. Validation to Class III also validates the same SSV/USV for Class II in accordance with scaling limitations specified in the document.

The validation requirements in this specification are not represented as duplicating actual well conditions.

Product Details

Edition:

2nd

Published:

02/01/2013

Number of Pages:

25

File Size:

1 file , 500 KB

Product Code(s):

G6AV102, G6AV102, G6AV102, G6AV102, G6AV102, G6AV102

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

API Spec 6AV1

Click here to purchase
There are three service classes – Class I, Class II, and Class III – for API 6A surface safety valve (SSV), underwater safety valve (USV), or boarding shutdown valve (BSDV). This standard establishes sandy service design validation for valves to meet Class II and Class III.

Class II is intended to validate the valve bore sealing mechanism if substances such as sand can be expected to cause safety or shutdown valve failure.

Class III adds additional requirements and validation of the bonnet assembly inclusive of stem seals and may be selected by the user/purchaser. Validation to Class III also validates the same SSV/USV/BSDV for Class II in accordance with scaling limitations specified in the document.

The validation requirements in this standard are not represented as duplicating actual well conditions. For actuated valves, validation of the actuator is outside the scope of this standard.

Product Details

Edition:

3rd

Published:

07/01/2018

Number of Pages:

32

File Size:

1 file , 720 KB

Redline File Size:

2 files , 5.3 MB

Product Code(s):

G6AV103, G6AV103, G6AV103, G6AV103, G6AV103, G6AV103

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria
