CGA E-9

Click here to purchase
CGA E-9 provides a minimum standard for flexible stainless steel braided hoses with the following inner core:

• ethylene tetrafluoroethylene (ETFE);
• polytetrafluoroethylene (PTFE); and
• corrugated stainless steel.

These hoses have a nominal inside diameter (ID) of 0.25 in (6.4 mm) or less and shall have a maximum allowable working pressure (MAWP) of at least 3000 psi (20 680 kPa) at 70 °F (21.1 °C). These flexible hoses are sometimes referred to as pigtails.

This standard does not cover requirements for other polymeric or elastomeric inner core hoses.

Product Details

Edition:

6th

Published:

02/19/2021

Number of Pages:

14

File Size:

1 file , 360 KB

CGA E-9

Click here to purchase
This publication provides a minimum standard for braided, ethylene tetrafluoroethylene (ETFE)-lined and pol-ytetrafluoroethylene (PTFE)-lined flexible hoses that have a nominal inside diameter (ID) of 0.25 in (6.4 mm) or less and shall have a maximum allowable working pressure (MAWP) of 3000 psi (20 680 kPa) at 70 °F (21.1 °C). These flexible hoses are sometimes referred to as pigtails.

This standard does not cover requirements for other polymeric or elastomeric line hoses.

Product Details

Edition:

5th

Published:

04/01/2017

Number of Pages:

10

File Size:

1 file , 590 KB
